SMA Female Straight 2-Hole, Field Replaceable (.015)

The SMA Female Straight 2-Hole, Field Replaceable (.015) from Amphenol CDI is engineered for reliability and precision in high-frequency signal transmission. Ideal for aerospace, defense, and telecommunications, this connector ensures consistent performance in demanding environments.

SKU: 5660-5CC

Distributor	Quantity	Buy

Specifications
Contact Us

Products specifications

Attribute name	Attribute value
Contact Termination	Field Rep.
Housing Finish	Gold
RF Connector Specifications
Body Style	Swept Right Angle
Impedance	50 ohms
Mounting Style	2 Hole PNL.
Gender	Female
Hermetic	No
Body Plating	Gold
Termination	COAX
Cable Termination	N/A
Dielectric Material	PTFE
Center Contact Material	BeCu
Voltage	335 Vrms max @ sea level
Mating Cycles	500 cycles min
Insertion Loss	.07 √f(GHz)
Max Frequency	18 GHz
Body Material	304L SST
Operating Temperature	-65°C to +150°C
T & M Specifications
Connector Type	Jack, Female Socket
