Coaxial Adapter 1.85mm Female (Jack) to 1.85mm Female (Jack)

Adapter Coaxial Connector 1.85mm Jack, Female Socket To 1.85mm Jack, Female Socket, 50 Ohms
SKU: TMA-8FS-8FS-00
Adapter Coaxial Connector 1.85mm Jack, Female Socket To 1.85mm Jack, Female Socket, 50 Ohms
Distributor Quantity Buy
Contact Us
Products specifications
Attribute name Attribute value
Category Coaxial Connector (RF) Adapters
Packaging Bag - Single
Contact Termination Compression
Housing Finish Passivated SST
Number of Ports 2
RF Connector Specifications
Gender Female to Female
Impedance 50 ohms
Mounting Style Free Hanging (In-Line)
Max Frequency 67 GHz
Center Contact Material BeCu
Body Material SST
Center Contact Plating Gold
Dielectric Material PTFE
Operating Temperature -55°C to + 85°C
Voltage 500 Vrms max @ sea level
Mating Cycles 500 cycles min
Insertion Loss 0.2 dB
T & M Specifications
Series Between Series
Connector Style 1.85 mm to 1.85 mm
Shield Termination Threaded
Fastening Type Threaded
*
*
*
